ProctorWrap Air Tight (AT) breathable membrane by Dynamic Composite Technologies


ProctorWrap Air Tight (AT) is a triple layer polypropylene textile developed primarily as a breathable membrane for use with timber and steel frame wall construction behind rain screen cladding's and as a vapour permeable underlay for supported metal roof applications.

ProctorWrap AT affords effective protection during construction and for the life of the building against rain, snow and dust, and allows for the controlled escape of vapour from within the building whilst restricting the ingress of moisture. All Proctor Roofshield and ProctorWrap breathable (vapour permeable) membranes have a vapour resistance of not more than 0.5 MNs/g when tested to AS/NZS 4200.1.

In combination with taping overlaps, ProctorWrap AT forms an air tight wrap for the building reducing the loss of heated air or cooled air from the building thus improving the energy efficiency of the building envelope.

Applications

  • Timber and steel frame wall construction behind rain screen cladding
  • Metal roofs

Features

  • Water resistant
  • Low vapour resistance
  • Air permeable
  • UV resistant
  • Supplied in 1.5 m x 50 m rolls
  • Light weight

Standards

  • Complaint with AS/NZS 4200.1
  • Manufactured in conformity with EN 13859-1:2

Product Name: ProctorWrap Air Tight

Product Description: A triple layer polypropylene textile developed primarily as a vapour permeable membrane and air tight wall wrap for use in timber and steel frame wall construction behind rain screen claddings and as vapour permeable underlay for fully supported metal roof applications.

Product Code: ProctorWrap AT
Colour: Grey
Width x Length: 1.5m x 50m (75m²)
Nominal thickness: 0.4mm
Nominal weight: 135g/m²
Burst strength: 294N to AS 2001.2.19
Flammability index: 1 (Low) to AS/NZS 1530.2
Edge tear resistance: 295N (MD) / 175N (CD) to TAPPI T470
Nail tear resistance: 95N (MD) / 110N (CD) to EN12310-1
Water vapour permeability: 3.9μg/N.s to ASTM E96
Water vapour resistance: 0.26 MNs/g to ASTM E96
Hydrostatic head: >2000mm to BS EN 20811
Resistance to water penetration: High to AS/NZS 4201.4
