Self-locking vee-grates and frames from HaveStock  For vee drains and dished channel drainage. Ideal for council roadways, carparks and residential subdivisions.
Features - Vee grating with special design bars to provide maximum water drainage.
- Self-locking grate into the frame by means of a spring bar (no need for bolts).
- 15° angle of fall.
- Bicycle safe design.
- Two part hinged grating for 700 and 800 dimensions.
- Durable ductile iron casting.
Grates and frames are manufactured from spheroidal graphite (SG or Ductile) cast iron in accordance with strandards ISO 1083 (grade 500-7) and EN 1563. Load classification Class D (210kN AS3996) and C250 of EN124. Coating - non-toxic water based black paint according to BS 3416.
For further information contact:
Havestock
phone: 07 3216 5000
fax: 03 3216 5222
web: www.havestock.com.au
|
