BAL 40 Double Hung Fire Window from Aneeta Window Systems

Aneeta Fire Window - BAL 40 Double Hung Windows

Aneeta Window Systems have developed their unique 'Aneeta Fire Window' in accordance with the recently revised Australian Standard AS3959:2009.

Compliant with Bushfire Attack Level (BAL) 40, and below, without the need for non-combustible shutters, the Aneeta Fire Window is a 2 Panel Double Hung Double Glazed system comprising of 16mm IG toughened glass units, suitable metal hardware and certified, low flammability indexed, seals.

Benefits

• BAL 40 compliant - Stylish and slim lined bushfire window
• Unique application - Large, narrow, curved or raked double hung
• Uninterrupted views - Designed with the smallest framing possible
• Energy efficient - 16mmIGUs provide superior thermal performance
• Sound reduction - Achieves acoustic (STC) rating of 33
• Child-safe Ventilation - 2 vent lock positions or full 50% opening area
• Patented performance -'Centre-fin' for security and weather resistance
• Custom fabrication - Your shape, size, glass option and colour

Design Criteria

• Glass - 5/6/5 or 4/6/6 toughened glass IG units.(Argon optional)
  - Selection subject to design choice and performance criteria
  - Visit WERS website to view Aneeta 'Window Energy Ratings'
• Application* - Aneeta Windows are 'insert' systems installed into suitable min.66mm Deep aluminium, timber or steel perimeter frames supplied by others (window fabricators, builders etc)
• Mesh - 'Mesh' screens to be supplied and externally fitted, by others, in accordance with AS3959:2009
• Size - Max.3.2m2 per window @ (40kg/IG panel at 25kg/m2)
  - 2 Equal Sashes of height:width ratios between 2:1 & 1:1.5

* Perimeter frames must comply with, and be installed and screened by others, in accordance with AS3959:2009

Please note: Standard 6mm, 10mm, 16mm & 22mm Aneeta sashless window systems, in all configurations, still comply in all bushfire prone areas from BAL12.5 to BAL-FZ (Flame Zone) when externally fitted with compliant metal screens or shutters in accordance with AS3959:2009.
