JD Neuhaus launches 125t Air Hoist

JD Neuhaus has announced the launch of a 125t air operated hoist in their EH range, believed to be the world's first air operated hoist with a lifting capacity of 125 tonnes. This product is the most powerful unit in the EH range of this internationally renowned Materials Handling and Lifting Specialist.

Designated as an EH 125 monorail hoist, the unit operates from 6 bar air pressure and is equipped with 10kW and 2.8kW rated motors for the lifting and traverse functions respectively. In standard format, the hoist is supplied with a six double-chain mechanism providing a three metre lift at speeds of 0.30 m/min at full load and 0.38 m/min on lowering. Horizontal travel speeds of 6 m/min are achieved with maximum load and 8 m/min when unloaded. A two metre length flexible connection is supplied with an ergonomic multi-function pendant controller for precise, infinitely variable control of the lift/lowering and traverse operations for safe, accurate load placements.

The hoist is specially designed for heavy industries such as steelworks, cement, chemical, power generation and shipbuilding plants as well as the oil and gas markets. The low-headroom design ensures that the hoist can be used where minimum operating space is available; while an Ex rating ensures suitability for use in hazardous areas where there is a potential risk of explosion. The product is 100% duty rated while also being insensitive to humidity and dust laden atmospheres, and can operate within a temperature range of -20°C to +70°C

As with all JDN high performance lifting products, standard safety features include a fail-safe brake to hold the load in the event of air supply failure, an emergency shut-off valve, anti-climb and anti-drop devices together with an emergency lowering device. Optional accessories include overload and increased spark protection, two speed trolley travel control and rack and pinion drive. Non-standard lift heights and remote radio-control operation can also be accommodated.

For further information, please contact Pacific Hoists on 02 8825 6900 or visit www.pacifichoists.com.au
