High Performance Alternative to F17 Hardwood from Hyne

Hyne LVL E-Beam+ engineered beams offer structural properties that are equivalent to or better than hardwood F17 at competitive prices and is engineered to maximise the efficient use of material and time. Because it is engineered, Hyne LVL E-Beam+ performs consistently and reliably and its behaviour is more predictable than traditional timber products.

This makes it easier to work with and reduces the builder's exposure to future maintenance problems.

Uniform engineering properties, high strength to weight ratio and availability in long lengths to suit specific jobs, makes Hyne LVL E-Beam+ a preferred choice over alternative building products.

Features

Engineered for straightness and consistent performance
High load bearing capacity
Available in lengths from 3.6m to 7.2 with longer lengths available as special manufacture up to 12.6m
Available in full range of section sizes
Available generally ex-stock
Competitively priced when compared with F17 hardwood
High strength yet lighter and safer to handle
Chamfered edges for safer and more comfortable handling
Manufactured from 100% plantation pine
Manufactured by a wholly owned Australian company

Uniform. High Strength. Dependable.

Treatments
Hyne LVL E-Beam+ is available in untreated or H2 S treated as specified in AS1604.4

Sizes
90, 120, 140, 190, 240, 290 x 35mm
90, 120, 140, 190, 240, 290 x 45mm

Lengths
Available in lengths from 3.6m to 7.2m with longer lengths available as special manufacture up to 12.6m

Adhesive
Phenolic - AS 2754.1

Bond
Type A - AS/NZS 2098.2

Characteristic Design Values
Stress grade - F17
Characteristic strength, MPa
Bending (f/b) - 50
Tension parallel to grain (f/t) - 30
Shear in beam (f/s) - 4.3
Compression parallel to grain (f/c) - 40

Characteristic short duration average modulus of elasticity parallel to the grain, MPa (E) - 14,000

The characteristic design values of Hyne LVL E-Beam+ apply only when the moisture content of the LVL is below 15% in service and are for 'on edge' orientation of the LVL section only.

Multiple Hyne LVL E-Beam+ Sections
The use of multiple Hyne LVL E-Beam+ sections is permitted using vertically nail laminated members. Multiple Hyne LVL E-Beam+ members are to be nailed laminated in accordance with C1 2.3 of AS1684.2 - 1997. For assistance with the engineering design of multiple Hyne LVL E-Beam+ members please call your Hyne Technical Advisor.
