Vertical lifts by Lift Sales
Model: EDS 18 Compact
Manufactured in Melbourne. Suitable for restricted space applications.
Not suitable for wheel chairs.
Application - Single Private Residence.
Standard - AS1735 Part 18.
Drive Mechanism - oil hydraulic, direct acting or roped.
Travel Distance - maximum of 12000mm.
Landings Served - up to 5.
Speed - 0.25 meters/second.
Rated Load - 240KG.
Lift Car Dimensions - 800mm x 800mm x 200mm.
Car Interior - standard or customised.
Landing Doors - 800mm Wide x 2040 High. Purchaser's choice of material and finish. Any painting or staining by others.
Car Telephone - provided, recessed in cabinet.
Headroom - 2700mm standard. Reduced headroom options available.
Pit Depth - 250mm.
Lift Shaft
- Steel self supporting tower as standard
- Crane in option available
- Installed into shaft provided by others optional
Power requirements - single phase.
Machine cabinet - supplied by manufacturer.
|
