Batch and hard anodising by the Anodising Association

Batch anodising involves racking parts and immersing them in a series of treatment tanks. Extrusions, sheets or bent metal parts, castings, cookware, cosmetic cases, flashlight bodies and machined aluminium parts are just a few of the items that are batch anodised.

Appearance options and quality are improved through the use of dyes and special pretreatment procedures. This makes the aluminium look like pewter, stainless steel, copper, brushed bronze or polished brass and can also be coloured with brilliant blues, greens, reds and many varieties of metallic gold and silver. The unique dielectric properties of an anodised finish offer many opportunities for electrical applications.

The surface of the aluminium itself is toughened and hardened to a degree unmatched by any other process or material. The coating is 30 percent thicker than the metal it replaces, since the volume of oxide produced is greater than that of the metal replaced. The resulting anodic coating is porous, allowing relatively easy colouring and sealing.

Hard anodising is a term used to describe the production of anodic coatings with film hardness or abrasion as their primary characteristic. They are usually thick by normal anodising standards (greater than 25 microns) and they are produced using special anodising conditions (very low temperature, high current density, special electrolytes). They find application in the engineering industry for components which require a very wear resistant surface such as piston, cylinders and hydraulic gear. They are often left unsealed, but may be impregnated with materials such as waxes or silicone fluids to give particular surface properties.
