Transparent Sector Rapid Door from Automatic Doors

Sector is a rapid door composed of several interchangeable sectors made from transparent PVC or coloured polyester. This solution offers great product versatility and numerous opportunities for adaptation to new requirements of use. The design is highly developed, compact and various.

It features very innovative characteristics, such as: a modern emergency system with devices for reopening the panel and preventing it from falling down again, an effective "anti-crash" device that protects the curtain and bar from any accidental impact, a modular counterweights balancing system that aids the functioning of the motorized system and permits semiautomatic reopening, but above all easy interchangeability of the sectors, with different coloured versions.

Maximum structural versatility is the hallmark of these rapid doors. According to requirements, flexible curtain panels can be combined with partially or wholly see-through ones so as to enhance visibility and safety.

Sector doors feature:

• modular panels
• a reliable modular counterweight balancing system with sturdy traction belts for minimum motor-working load. The counterweights also ensure against accidental door dropping (as prescribed by Decree No. 626/94)
• a safety edge for immediate reversal of door movement with an ACS anti-crash system fitted along the edge which, through special skid with preset breaking load, prevent door and edge being damaged in case of accidental impact
• an outside control board built to IEC standards, with self-test function and with the most advanced operating logic
• an emergency release, available on both sides of the door, for disengaging the counterweight balancing system so as to permit manual reopening of the door
• quick polarized wiring for quick and correct electrical connections
• a three-phase actuator for intensive use comprising motor, reduction gear, brake, limit switch and release in a single integrated module
• a dc motor (optional) complete with batteries affording a number of advantages such as operating continuity in case of power failure, last opening/closing maneuver or emergency release as well as adjustable speed with acceleration and deceleration ramps.
