The 4m Electric Platform Lift is designed to fit into any environment and suit any project. It is our most versatile platform lift, tailored to meet your needs and tastes. It has a variety of functional features and interior or exterior design options, including a range of colours and optional glass modules.
It is supplied with an integral structure and cladding in either steel or glass and is an attractive, functional feature in any building.
- Sectors:
- Public Access.
- Private Access.
- Compliance:
- Platform Size:
0.15 m/s Speed, 415V 3 Phase (with a Single Phase option), 410kg (or 5 people), and up to 4000mm of travel
Features:
- 50mm pit or ramp.
- Low headroom.
- No external machine room.
- Round aluminium handrail.
- Perimeter safety edge.
- Tactile/braille hold-to-run, emergency stop & alarm buttons, key lockable controls.
- Autodialler phone.
- Shaft colour - RAL 9016 Trafic white (standard).
- 900mm clear door opening.
- Battery powered emergency lowering.
Platform:
- Full height wall.
- Vinyl, rubber or aluminium floor.
- Platform colour.
Doors:
- Solid.
- Glass panoramic.
- Auto operation.
Shaft:
- Glass infills.
- Custom RAL colour.
- Extra low head room option.
