SPECIFICATIONS AT A GLANCE

Core
Panel cores are self-extinguishing grade expanded polystyrene Class SL, manufactured to Australian standards. Steel skins are bonded to the core under pressure using a two part thermosetting polyurethane adhesive. Other specialised cores are also available on request.

Skins
Sheet thickness ranges. The external weather skin is standard at 0.40mm with a 100mm profile of 0.75mm depth with a 34mm rib forming the weather-joint. The internal skin is optional and can range from 0.40mm to 0.60mm. thickness.

Panel skins are available with a choice of steel:

• Colorbond® Permagard™ steel, incorporating Microban® antibacterial technology in its coating to provide durable, food-safe performance that will not wash off. This steel is available in Permagard™ White only.
• Colorbond® standard grade steel comes in a wide range of designer colours.
• There are other skin materials available on request, including Colorbond® Stainless steel and Ultra steel for severe coastal and industrial environments.

Colour
The many colours available in Colorbond® range from traditional to modern. For Prestige Applications there is Colorbond® Metalic steel. Generally, the lighter colours are preferred for external use, because they reflect solar radiation. The various surfaces and colour choice can influence the price per square metre - our sales staff will gladly assist you in your selection.

Dimensions

• Width: 1200mm as a modular standard.
• Thickness: 75 to 200mm in multiples of 25mm.
• Length: As required, determined by handling, design and transportation.

Profiles
The internal skin is available with a flat surface finish or low profile of 0.75mm depth: 100mm Rib profile, 50mm Mesa Rib and Silkline. The Askin Slip-joint® is incorporated into the edges of the internal skin for easy installation.
