Express Commercial Lifts from Grant Elevators

Express MRL Lift

Intended primarily for commercial applications, the Express MRL is also suitable for multi-storey residential buildings. It is available in sizes that carry from eight to 33 passengers.

The absence of a separate motor room reduces both the floor area and quantity of building materials required. The immediate benefits are increased architectural freedom and lower construction costs.

There are also significant advantages in long-term energy consumption and environmental protection. The Express MRL uses approximately 30 per cent less electricity than a conventional hydraulic lift and only a negligible amount of lubricating oil.

Design Features

• BCA part E3 compliant
• Rated speed 1.0 - 1.6m/s
• Available in sizes to carry 8 - 33 passengers (630kg - 2500kg)
• Enhanced system performance with reduced power and energy consumption
• Advanced gear-less drive system and inverter reduces noise both inside and out side the shaft, and increases passenger ride comfort
• Available with multiple entrance arrangements, including 90 degrees
• Automatic return to floor under power failure conditions as standard
• Full height 2D 'Curtain of Light' entrance protection
• Emergency telephone system with 24hr support
• Wide range of finishes to select from
