In-slab floor heating from P.A.P. Heating Solutions

Electric in-slab heating uses heating cables embedded in a concrete slab floor to provide home heating. The slab stores the heat at night, and releases it to provide continuous warmth to the home during the day. Using off-peak electricity, in-slab heating in an economical method of providing 24 hour heating, is set at a suitable temperature in a well insulated home. No other heating system provides the all-around benefits of in-slab heating: individual room thermostats, versatility, safety, silent and allergy free operation. Plus the total freedom of decor and furniture layout.

Elektra VCD35 Twin In-slab Heating Cable
Elektra Twin heating cables are available in ready made sets in a comprehensive range of lengths. Their convenient 'twin' design means installation is straight forward - you simply starts at the power source and work to the end of the cable, saving time and expense. They also come packaged on reels which means a kink and twist-free roll out. Elektra VCD35 cable is suitable for new construction and renovations as an in-slab heating systems or it can be installed after construction in an 25mm cement-based screed under many different flooring surfaces including timber, stone, tiles (ceramic & vinyl), parquetry and low profile carpet.

Elektra Twin Heating Mat
The Elektra Heating Mat is a twin cable on a fibreglass mat with a single sided power supply and is thermostat controlled. Elektra Heating Mats may be used under any type of floor suitable for heating, i.e. under any floor which radiates heat easily, such as floor tiles, slate, low pile carpet or some wooden floor panels. They are fixed directly to a prepared floor in a screed of self leveling compound or a cement based screed. At 0.5m wide and available at lengths from 2m to 16m they can be easily shaped to suits the floor layout. No special tools are required.

Microtemp Thermostats
The range of OJ Electronic thermostats are specially developed for control of electrical under floor heating. Their elegant design is suitable for vertical flush mounting in a standard wall bracket or DIN rail mount in switchboards (16amp & 2 pole switch). The thermostats include either a floor sensor or air sensing - the temperature is controlled with an accuracy of 0.4°C. The Range MTS + standard room mounts; MCC2 - built in 4 event clock; ETN - DIN-rail mounting; ETS - snow and ice.
