Fire Rated Insulation from Askin Performance Panels

SPECIFICATIONS AT A GLANCE

Core
Panel cores are fire-resistant XFlam™ based on syntactic technology.
XFlam™ comprises a composite blend of specific phenolic resins and various filling materials, manufactured to Australian standards.
Steel skins are bonded to the core under pressure using a twopart thermosetting polyurethane adhesive.

Skins
Sheet thickness can range from 0.40mm to 0.60mm for either surface skin. Panel skins are available with a choice of steel:

• Colorbond® Permagard™ steel, incorporating Microban® antibacterial technology in its coating to provide durable, foodsafe performance that will not wash off. This steel is available in Permagard™ White only.
• Colorbond® standard grade steel comes in a wide range of designer colours.
• There are other skin materials available on request, including Stainless Steel, Aluminium and Printech™ printed steel.

Colour
The many colours available in Colorbond® range from traditional to modern. For Prestige Applications there is Colorbond® Metalic steel. Generally, the lighter colours are preferred for external use, because they reflect solar radiation. The various surfaces and colour choice can influence the price per square metre - our sales staff will gladly assist you in your selection.

Dimensions

• Width: 1200mm as a modular standard.
• Thickness: 50 to 250mm in multiples of 25mm.
• Length: Cut to order, a minimum length 1000mm to a maximum of 22000mm.

Profiles
Available with a flat surface finish or low profile of 0.75mm depth to either surface: 100mm Rib profile, 50mm Mesa Rib and Silkline. The Askin Slip-joint® is incorporated into the edges of both surface skins for easy installation.
