TECHNICAL DATA

Technical Information
Material: Quarzsand
Age: 40 million years
Origin: Germany
Weight: 5000g/m2

Test results from independent Technical Institutions in Germany and Australia
Fire Properties
DIN 4102, sec1,6.2 DIN 4102, sec14
AS/NZS 3837, Group
In accordance with SpecificationA2.4 Australian Building Code
Non-readily ignitable (low flame spread)
(DIN 4102-B1) PA-111 2.768
(The building material classification DIN 4102-B1 is applicable on metallic or solid mineral basis)
B1 tested and approved
Critical Emission intensity>1.1
Integral value of light attenuation 0-0.7

Castor chair wear factor
DIN EN 425
No visible alteration after 75000 revolutions.

Formaldehyde
Cladstone is formaldehyde free

Abrasion classification
DIN 52368
No visible alteration after 100000 revolutions

Staining/Cleaning
DIN 51958 (EN 423)

Slip-resistance
R 13 (inclination>35)

Dimensional stability
DIN 434, DIN 51967, DIN 16860
Manufacture alignment 0.14mm
Right angle to manufacture alignment 0.05mm-017mm minimalNegligible measurement alterations 0.03mm-0.17mm

Peel resistance
DIN 16860
With normal climate and heating conditions 1.76-1.98 N/mm

Heat penetration
Din 66098 Standard for under floor heating.
