Wide Span Insulated Roof Panels from Versiclad

CORROLINK S ROOFING PANELS

One of our most popular insulated roof panels, Corrolink-S is now available 1000mm wide offering greater spans and R Values than ever before. Corrolink-S only requires a minimum 3° fall, can a achieve a cantilever up to 2.89 metres and a larger side eave of up to 450mm offering a versatile design from heritage to modern.

With a corrugated top skin available in a variety of different colours and a flat ceiling face offering 3 different finishes. With 6 different thicknesses to choose from, Corrolink-S can achieve RT values up to 5.0, a huge insulation level for your home as well as amazing trafficable spans of up to 9.0m.

Why should you use Corrolink-S?

• Minimum Roof Pitch now only 3° in non tropical areas
• 1000mm wide panels means less panels, less visible ceiling joints meaning less labour
• Long trafficable unsupported span of up to 9.0 metres means less unsightly support beams
• Huge cantilever abilities up to 2.89 metres
• Greater R Values up to RT5.0
• Larger side eaves of up to 450mm (based on full width panel)
• Higher grade core, now available with S Grade Polystyrene
• Custom lengths available from 1200mm to 9000mm
• Lightweight and easy to install
• Wiring services run through core ducts
• Fire retardant EPS insulated core dramatically reduces radiant heat transfer, mould, condensation and rain noise
• Fire flashings available to meet BAL-40 specifications
• Ceiling fan mounting plates available
• LED downlights available
• Solar panel installation engineering available
