Flush Partitions Australia

Squareline Cubicle System from Flush Partitions Australia


Squareline Modified builds on our most popular washroom cubicle system, but with a twist. While the standard Squareline system features frontals mounted on an aluminium leg, and overhead bracing, the Squareline Modified has a more seamless appearance with frontals extending from floor to ceiling. This gives an appearance of a full height cubicle system.

Materials
Squareline Modified can be manufactured using 13mm multi-purpose compact laminate board, or 18mm or 33mm pre-laminated board.

Sizes and Configurations
Typical standard toilet cubicle size is 900mm wide x 1500mm deep overall. For showers, this depth can be extended to 1800mm overall with the inclusion of a wing wall and shower seat.

The Squareline Modified can also be manufactured to suit non-standard sizes, in accordance with design or building requirements.

The Squareline Modified system is set 200mm above the finished floor level, with the exception of the frontal blades which are fixed to the floor and over-flashed with 110mm high brushed satin stainless steel plinth flashing and finish to the underside of the ceiling.
